HYDRA Ironmaster 1" - Iron Filter Well Water Filter Home Water Filter

HYDRA Ironmaster 1” - iron filter for well water, house water filter

Powerful triple filter housing

Robust construction – efficient water treatment

The powerful 3-stage filter housing ensures reliable and long-lasting water treatment. The system combines state-of-the-art filter technologies for clean water that is odor- and taste-neutral – ideal for drinking water, well water, and household water applications.

The iron filter cartridge reduces the iron concentration, hydrogen sulfide content, and the metallic taste and odor of the water, and helps normalize the water's pH value. To do this, the filter oxidizes hydrogen sulfide, converting Fe² to Fe³.

The activated carbon filter consists of compressed activated carbon and filters contaminants from the water such as chlorine, organic pollutants, light hydrocarbons, solvents, pesticides, insecticides, oils and flavors, taste impairments, odor impairments, fine particles, and suspended solids.

Water with too high an iron content is the main cause of wear in industrial systems and household appliances due to deposits of so-called "scale". Iron salts damage textiles washed in such water and irritate the skin. Furthermore, excessive iron content in the water leads to rust stains on sanitary fittings.

The innovative backwash system with spring-loaded filter cartridge. When the flushing valve is opened, the pressure drop pulls the cartridge downward, cleaning it from the inside as well. A minimum pressure of 1.8 bar is required to ensure backwashing.

 Reduction of substances (max. application values)

• Iron: up to 4.0 mg/l usable

• Manganese: up to 0.1 mg/l usable

• Sulfite: up to 0.9 mg/l

• Oxide: up to 4.0 mg/l

• Chloride: up to 4.8 mg/l

• Silicates: up to 35.0 mg/l

Use & benefits

✔ Space-saving, 3-stage water treatment system
✔ Easy and quick installation
✔ Includes hose connector and drain funnel
✔ Backflow protection according to UNI EN 1717-11/2002
✔ Hydra Trio well water filter with integrated drain funnel
✔ Optimal protection for the drinking water supply

The individual filtration stages:

1 x RLH - prefiltration cartridge - (EAN: 8021647070418)
Self-cleaning prefiltration cartridge – RLH: 90 MIC
filters sand and other particles larger than 90 microns
Service life: approx. 12-24 months (depending on water quality and flow rate)

1 x PFEX Iron iron filter (EAN: 4260303250830)
reduces the iron concentration, hydrogen sulfide content, the metallic taste, the smell of the water and helps normalize the water's pH value.
Service life: approx. 6 months or approx. 3,000 ltr. (depending on the iron (max. 4 mg/l) and manganese levels (max. 0.1 mg/l) and the flow rate)

Note: With PFEX iron removal filters, it may happen that granulate dust initially comes out, which is created during transport. Let the water run until it is clear. Please also observe the maximum values. If necessary, carry out a water analysis before installing the filter to determine the iron content of the water.


1 x CB activated carbon block (EAN: 4260303250106)
filters chlorine, org. pollutants, light hydrocarbons, solvents, pesticides, oils and flavors, taste impairments, odor impairments, fine particles (rust, lime flakes, sand, flakes) and suspended solids.
Service life: approx. 6 months (depending on water quality and flow rate)


You will receive the filtration system in its original packaging, with filter housing, a housing wrench, a wall bracket, screws, and three filter cartridges.
